Inconel Instrumentation Valves

Home > Inconel > Inconel Instrumentation Valves

Jassem Tube Fittings is a trusted manufacturer and supplier in Doha, Qatar, offering high-quality Inconel Instrumentation Valves designed for precise flow control and dependable performance in extreme operating conditions. These valves are engineered to handle high pressure, high temperature, and highly corrosive media while maintaining accuracy and tight sealing. Manufactured with precision machining and strict quality standards, Jassem Tube Fittings ensures reliability and long service life. Inconel alloys are well known for their strength and resistance to oxidation and corrosion, making these instrumentation valves an ideal choice for critical industrial applications.

Inconel Process Control Valve In Doha, ASTM A494 Grade CY40 Ferrule Valve Al Rayyan, Inconel High Pressure Valves Al Wakrah, ASTM A494 Grade CY40 Low-Pressure Valve Al Khor, A494 Grade CW6MC Instrumentation Valve Al Shahaniya, Inconel 600 Hydraulic Valves Doha, Qatar.

Inconel Instrumentation Valves are made from nickel-chromium-based alloys with additions of iron, molybdenum, and niobium to enhance strength and corrosion resistance. The alloy offers excellent resistance to oxidation, pitting, and stress corrosion cracking. Mechanically, Inconel provides high tensile and yield strength, outstanding creep resistance, and toughness at elevated temperatures. It maintains structural integrity under extreme pressure and thermal cycling, ensuring smooth operation, reliable sealing, and consistent performance in harsh and aggressive service conditions.

Inconel Instrumentation Valves Specifications

Media

Oil, Gas & Water

Temperature of Media

Medium Temperature

Pressure & Temperature Limit accordance to ANSI/ASME B16.34

Alloy 625 (PSI/ Bar)
Class 2500	6000 psig/414 bar
Class 4500	10000 psig/689 bar

Operation Way

Manual, Electric actuator, Pneumatic

Standard

3A/ ISO/ DIN/ SMS / ASTM / JIS

Brand Name

OS-LOK

Packaging Details

PVC package, wooden case or as per customer’s requirement.

Leakage rate

Soft Seal: zero leakage, 100% Leak test
Hard Seal ≤ Rated Flow 10-5

Working pressure

3000 psig (206 bar)

Seal ring material

PPL, PTFE, PPL Soft Graphite

Manufacturing Process

Forged bar stock

OEM service

Yes

Connection

Single Ferrule
Two Ferrule (Double Ferrule)
Twin Ferrule
Thread

Thread Type

BSPP
C.61 4-Bolt Flange
C.61 Combo 4B + Split
C.61 Split Flange
C.62 4-Bolt Flange
C.62 Combo 4B + Split
C.62 Split Flange
ISO 6149
NPT
SAE

Function

2-Way
3-Way
4-Way
5-Way
Diverter
Normally Closed
Normally Open

Flow Rate

.93, 2.34, 6.42, .70, 1.04, 3.62,.87 Cv

Applicable Standard

Design & Manufacture : BS 1868
Face to Face according to : ASME B16.10
Flange Dimensions as per: ASME B16.5
Pressure & Temperature : ASME B16.34
Test & Inspection accordance to : API 6D / API 598
Visual Inspection accordance to : MSS SP-55
Marking accordance to : MSS SP-25

Inconel Instrumentation Valves Equivalent

GRADE / ALLOY	UNS Number	FORGING	CASTING	BARSTOCK
Alloy 800	N08800	B564 N08810	–	B408 N08800
Alloy 825	N08825	–	–	B425 N08825
Alloy 600	N06600	B564 N06600	A494 CY40	B166 N06600
Alloy 625	N06625	B564 N06625	A494 CW 6MC	B446 N06625

Top Inconel Instrumentation Valves Manufacturing Company in Doha

At Jassem Tube Fittings, we are a leading supplier, manufacturer, and exporter of Inconel Instrumentation Valves in Doha, Qatar. Our state-of-the-art manufacturing facilities, strategically located in the Qatar, enable us to deliver high-quality solutions that meet your specific requirements. With a comprehensive inventory of Monel materials, we are well-equipped to fulfill your needs efficiently. Our commitment to excellence and customer satisfaction ensures that we consistently maintain a ready stock of Monel Manifold Valves to support your operational demands.

Types of Inconel Instrumentation Valves

Incoloy Hydraulic Valves available in all types such as Needle, Check, Butterfly and Globe Valves Doha, Inconel Exhaust Valves Al Rayyan, Inconel 625 Valves Al Wakrah, Inconel Valves Al Khor, Instrumentation ASTM A494 CY40 Class 2 Inconel 600 Exhaust Valves manufacturer & supplier Al Shahaniya, Inconel 600 Valves In Doha, Qatar.

Largest Manufacturer and Supplier of Inconel Instrumentation Valves in Doha, Qatar

Jassem Tube Fittings is a leading supplier and stockist of premium Inconel Instrumentation Valves in Doha, Qatar. Our products find extensive application across diverse industries, and we are dedicated to delivering outstanding service while ensuring high customer satisfaction. Our specialized finishing techniques distinguish us in the metal industry, enhancing the performance and durability of our valves. We are committed to consistently providing top-quality Monel Manifold Valves while effectively addressing the unique needs of our customers.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Inconel Instrumentation Valves Uses

Inconel Instrumentation Valves supplied by Jassem Tube Fittings are widely used in oil and gas, petrochemical, chemical processing, and power generation industries. They are ideal for controlling flow in instrumentation lines, sampling systems, and high-pressure pipelines exposed to extreme heat and corrosive fluids. These valves are commonly installed in refineries, offshore platforms, boilers, and steam systems where reliability and safety are critical. Their durability, precise control, and resistance to harsh environments make them essential for maintaining accurate measurements and long-term performance in critical process and instrumentation systems.
