Based in Doha, Qatar, Jassem Tube Fittings stands out as a top-notch manufacturer and supplier of high-quality instrumentation and flow control solutions, including their renowned Stainless Steel Manifold Valve. The company prides itself on precision manufacturing, rigorous quality standards, and reliable performance in even the toughest industries. Their Stainless Steel Manifold Valves are expertly designed for precise pressure control, isolation, and venting in process and instrumentation systems. Built to endure harsh operating conditions, these valves boast impressive corrosion resistance and leak-free operation. With a strong focus on customer satisfaction and engineering excellence, Jassem Tube Fittings provides dependable valve solutions tailored to meet industrial needs across the Middle East.
Stainless Steel Manifold Valves are typically crafted from high-quality stainless steel grades like SS304, SS316, and SS316L. Their composition features iron combined with chromium for corrosion resistance, nickel for added toughness, and molybdenum to enhance resistance against pitting and crevice corrosion. On the mechanical side, these valves deliver high tensile and yield strength, exceptional pressure-handling capabilities, and solid fatigue resistance. They maintain their shape and sealing integrity even under high pressure and temperature fluctuations, ensuring consistent performance, durability, and safety in demanding industrial and instrumentation settings.
| BRAND NAME | Jassem Tube Fittings |
| STAINLESS STEEL MANIFOLD VALVES SIZE | 1/8″ TO 1″ |
| THREAD | NPT, BSPP, BSPT |
| STAINLESS STEEL MANIFOLD VALVES CONNECTION | THREADED, FLANGE END |
| TYPE | R TYPE, T TYPE, H TYPE |
| FUNCTION | 2 WAY, 3 WAY, 5 WAY |
| STAINLESS STEEL MANIFOLD VALVES BODY SHAPE | SQUARE, RECTANGLE |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15,000 PSI |
| STAINLESS STEEL MANIFOLD VALVES ORIFICE SIZE | 2 MM TO 9.5 MM |
| MEDIA TEMPERATURE | (-120* C TO 500*C ) RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK, FORGED |
| STAINLESS STEEL MANIFOLD VALVES HANDLE | BAR T-HANDLE |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| EQUIVALENT BRANDS | SWAGELOK, PARKER, ROSE MOUNT, HAMLET, OLIVER VALVES, HOKE |
| STAINLESS STEEL MANIFOLD VALVES MATERIAL | SS 316, SS 304, SS 316 TI, 904L |
| Classification | Specification | Chemical Composition | other | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| JIS | AISI | C | Si | Mn | P | S | Ni | Cr | Mo | Cu | N | ||
| Martensitic Grades | SUS403 | 403 | 0.015 | 0.050 | 1.000 | 0.0040 | 0.0030 | (1) | 11.050~13.000 | – | – | – | – |
| SUS410 | 410 | 0.015 | 1.000 | 1.000 | 0.0040 | 0.0030 | (1) | 11.050~13.050 | – | – | – | – | |
| SUS410J1 | – | 0.008~0.018 | 0.060 | 1.000 | 0.0040 | 0.0030 | (1) | 11.050~14.000 | 0.030~0.060 | – | – | – | |
| SUS410F2 | – | 0.015 | 1.000 | 1.000 | 0.0040 | 0.0030 | (1) | 11.050~13.050 | – | – | – | Pb 0.005˜0.030 | |
| SUS416 | 416 | 0.015 | 1.000 | 1.025 | 0.0060 | Min.00.015 | (1) | 12.000~14.000 | (2) | – | – | – | |
| SUS420J1 | 420 | 0.016~0.025 | 1.000 | 1.000 | 0.0040 | 0.0030 | (1) | 12.000~14.000 | – | – | – | – | |
| SUS420J2 | 420 | 0.026~0.040 | 1.000 | 1.000 | 0.0040 | 0.0030 | (1) | 12.000~14.000 | – | – | – | – | |
| SUS420F | 420F | 0.026~0.040 | 1.000 | 1.025 | 0.0060 | Min.00.015 | (1) | 12.000~14.000 | (2) | – | – | – | |
| SUS420F2 | – | 0.026~0.040 | 1.000 | 1.000 | 0.0040 | 0.0030 | (1) | 12.000~14.000 | – | – | – | Pb 0.005~0.030 | |
| SUS431 | 431 | 0.020 | 1.000 | 1.000 | 0.0040 | 0.0030 | 1.025~2.050 | 15.000~17.000 | – | – | – | – | |
| SUS440A | 440A | 0.060~0.075 | 1.000 | 1.000 | 0.0040 | 0.0030 | (1) | 16.000~18.000 | (3) | – | – | – | |
| SUS440B | 440B | 0.075~0.095 | 1.000 | 1.000 | 0.0040 | 0.0030 | (1) | 16.000~18.000 | (3) | – | – | – | |
| SUS440C | 440C | 0.095~1.020 | 1.000 | 1.000 | 0.0040 | 0.0030 | (1) | 16.000~18.000 | (3) | – | – | – | |
| SUS440F | S44020 | 0.095~1.020 | 1.000 | 1.025 | 0.0060 | Min.00.015 | (1) | 16.000~18.000 | (3) | – | – | – | |
| Ferritic Grades | SUS405 | 405 | 0.008 | 1.000 | 1.000 | 0.0040 | 0.0030 | – | 11.050~14.050 | – | – | – | Al 0.010~0.030 |
| SUS410L | – | 0.003 | 1.000 | 1.000 | 0.0040 | 0.0030 | – | 11.000~13.050 | – | – | – | – | |
| SUS430 | 430 | 0.012 | 0.075 | 1.000 | 0.0040 | 0.0030 | – | 16.000~18.000 | – | – | – | – | |
| SUS430F | 430F | 0.012 | 1.000 | 1.025 | 0.0060 | Min.00.015 | – | 16.000~18.000 | (2) | – | – | – | |
| SUS434 | 434 | 0.012 | 1.000 | 1.000 | 0.0040 | 0.0030 | – | 16.000~18.000 | 0.075~1.025 | – | – | – | |
| SUS447J1 | – | 0.001 | 0.040 | 0.040 | 0.0030 | 0.0020 | – | 28.050~32.000 | 1.050~2.050 | – | 0.0015 | – | |
| SUSXM27 | – | 0.001 | 0.040 | 0.040 | 0.0030 | 0.0020 | – | 25.000~27.050 | 0.075~1.050 | – | 0.0015 | – | |
| Austenitic Ferritic Grades | SUS329J1 | 329 | 0.008 | 1.000 | 1.050 | 0.0040 | 0.0030 | 3.000~6.000 | 23.000~28.000 | 1.000~3.000 | – | – | – |
| SUS329J3L | S31803 | 0.003 | 1.000 | 2.000 | 0.0040 | 0.0030 | 4.050~6.050 | 21.000~24.000 | 2.050~3.050 | – | 0.008~0.020 | – | |
| SUS329J4L | S31260 | 0.003 | 1.000 | 1.050 | 0.0040 | 0.0030 | 5.050~7.050 | 24.000~26.000 | 2.050~3.050 | – | 0.008~0.030 | – | |
| Austenitic Grades | SUS201 | 201 | 0.015 | 1.000 | 5.050~7.050 | 0.0060 | 0.0030 | 3.050~5.050 | 16.000~18.000 | – | – | 0.025?? | – |
| SUS202 | 202 | 0.015 | 1.000 | 7.050~10.000 | 0.0060 | 0.0030 | 4.000~6.000 | 17.000~19.000 | – | – | 0.025 | – | |
| SUS301 | 301 | 0.015 | 1.000 | 2.000 | 0.0045 | 0.0030 | 6.000~8.000 | 16.000~18.000 | – | – | – | – | |
| SUS302 | 302 | 0.015 | 1.000 | 2.000 | 0.0045 | 0.0030 | 8.000~10.000 | 17.000~19.000 | – | – | – | – | |
| SUS303 | 303 | 0.015 | 1.000 | 2.000 | 0.0200 | Min.00.015 | 8.000~10.000 | 17.000~19.000 | (2) | – | – | – | |
| SUS303Se | 303Se | 0.015 | 1.000 | 2.000 | 0.0200 | 0.0060 | 8.000~10.000 | 17.000~19.000 | – | – | – | Se Min.00.015 | |
| SUS303Cu | – | 0.015 | 1.000 | 3.000 | 0.0200 | Min.00.015 | 8.000~10.000 | 17.000~19.000 | (2) | 1.050~3.050 | – | – | |
| SUS304 | 304 | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 8.000~10.050 | 18.000~20.000 | – | – | – | – | |
| SUS304L | 304L | 0.003 | 1.000 | 2.000 | 0.0045 | 0.0030 | 9.000~13.000 | 18.000~20.000 | – | – | – | – | |
| SUS304N1 | 304N | 0.008 | 1.000 | 2.050 | 0.0045 | 0.0030 | 7.000~10.050 | 18.000~20.000 | – | – | 0.010~0.025 | – | |
| SUS304N2 | – | 0.008 | 1.000 | 2.050 | 0.0045 | 0.0030 | 7.050~10.050 | 18.000~20.000 | – | – | 0.015~0.030 | Nb 0.015 | |
| SUS304LN | 304LN | 0.003 | 1.000 | 2.000 | 0.0045 | 0.0030 | 8.050~11.050 | 17.000~19.000 | – | – | 0.012~0.022 | – | |
| SUS304J3 | – | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 8.000~10.050 | 17.000~19.000 | – | 1.000~3.000 | – | – | |
| SUS305 | 305 | 0.012 | 1.000 | 2.000 | 0.0045 | 0.0030 | 10.050~13.000 | 17.000~19.000 | – | – | – | – | |
| SUS309S | 309S | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 12.000~15.000 | 22.000~24.000 | – | – | – | – | |
| SUS310S | 310S | 0.008 | 1.050 | 2.000 | 0.0045 | 0.0030 | 19.000~22.000 | 24.000~26.000 | – | – | – | – | |
| SUS316 | 316 | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 10.000~14.000 | 16.000~18.000 | 2.000~3.000 | – | – | – | |
| SUS316L | 316L | 0.003 | 1.000 | 2.000 | 0.0045 | 0.0030 | 12.000~15.000 | 16.000~18.000 | 2.000~3.000 | – | – | – | |
| SUS316N | 316N | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 10.000~14.000 | 16.000~18.000 | 2.000~3.000 | – | 0.010~0.022 | – | |
| SUS316LN | 316LN | 0.003 | 1.000 | 2.000 | 0.0045 | 0.0030 | 10.050~14.050 | 16.050~18.050 | 2.000~3.000 | – | 0.012~0.022 | – | |
| SUS316Ti | – | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 10.000~14.000 | 16.000~18.000 | 2.000~3.000 | – | – | Ti Min.05xC% | |
| SUS316J1 | – | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 10.000~14.000 | 17.000~19.000 | 1.020~2.075 | 1.000~2.050 | – | – | |
| SUS316J1L | – | 0.003 | 1.000 | 2.000 | 0.0045 | 0.0030 | 12.000~16.000 | 17.000~19.000 | 1.020~2.075 | 1.000~2.050 | – | – | |
| SUS316F | – | 0.008 | 1.000 | 2.000 | 0.0045 | Min.00.010 | 10.000~14.000 | 16.000~18.000 | 2.000~3.000 | – | – | – | |
| SUS317 | 317 | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 11.000~15.000 | 18.000~20.000 | 3.000~4.000 | – | – | – | |
| SUS317L | 317L | 0.003 | 1.000 | 2.000 | 0.0045 | 0.0030 | 11.000~15.000 | 18.000~20.000 | 3.000~4.000 | – | – | – | |
| SUS317LN | – | 0.003 | 1.000 | 2.000 | 0.0045 | 0.0030 | 11.000~15.000 | 18.000~20.000 | 3.000~4.000 | – | 0.010~0.022 | – | |
| SUS317J1 | – | 0.004 | 1.000 | 2.050 | 0.0045 | 0.0030 | 15.000~17.000 | 16.000~19.000 | 4.000~6.000 | – | – | – | |
| SUS836L | – | 0.003 | 1.000 | 2.000 | 0.0045 | 0.0030 | 24.000~26.000 | 19.000~24.000 | 5.000~7.000 | – | 0.025 | – | |
| SUS890L | – | 0.002 | 1.000 | 2.000 | 0.0045 | 0.0030 | 23.000~28.000 | 19.000~23.000 | 4.000~5.000 | 1.000~2.000 | – | – | |
| SUS321 | 321 | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 9.000~13.000 | 17.000~19.000 | – | – | – | Ti Min.05xC% | |
| SUS347 | 347 | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 9.000~13.000 | 17.000~19.000 | – | – | – | Nb Min.010xC% | |
| SUSXM7 | 304Cu | 0.008 | 1.000 | 2.000 | 0.0045 | 0.0030 | 8.050~10.050 | 17.000~19.000 | – | 3.000~4.000 | – | – | |
| SUSXM15J1 | – | 0.008 | 3.000~5.000 | 2.000 | 0.0045 | 0.0030 | 11.050~15.000 | 15.000~20.000 | – | – | – | – | |
| Precipitation Hardening Grades | SUS630 | S17400 | 0.007 | 1.000 | 1.000 | 0.0040 | 0.0030 | 3.000~5.000 | 15.000~17.050 | – | 3.000~5.000 | – | Nb 0.015~0.045 |
| SUS631 | S17700 | 0.009 | 1.000 | 1.000 | 0.0040 | 0.0030 | 6.050~7.075 | 16.000~18.000 | – | – | – | ||
| Grade | Melting Point | Density | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 304/ 304L | 1400 °C (2550 °F) | 8.0 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 35 % |
| 304H | 1400 °C (2550 °F) | 8.0 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 40 % |
| 310 / 310S / 310H | 1402 °C (2555 °F) | 7.9 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 40 % |
| 306/ 316H | 1400 °C (2550 °F) | 8.0 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 35 % |
| 316L | 1399 °C (2550 °F) | 8.0 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 35 % |
| 317 | 1400 °C (2550 °F) | 7.9 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 35 % |
| 321 | 1457 °C (2650 °F) | 8.0 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 35 % |
| 347 | 1454 °C (2650 °F) | 8.0 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 35 % |
| 904L | 1350 °C (2460 °F) | 7.95 g/cm3 | Psi 32000 , MPa 220 | Psi 71000 , MPa 490 | 35 % |
At Jassem Tube Fittings, we are the largest supplier, manufacturer, and exporter of Stainless Steel Manifold Valves in Doha, Qatar. Our state-of-the-art manufacturing facilities, strategically located in the Qatar, enable us to deliver high-quality, customized solutions to meet your specific needs. With an extensive inventory of over 16,000 tons of premium stainless steel materials, we are fully equipped to fulfill your requirements efficiently. Our dedication to excellence ensures that we consistently maintain stock availability to support your demands with prompt and reliable service.
| STANDARD | WERKSTOFF NR. | JIS | UNS | BS | AFNOR | GOST | EN |
| SS 304 | 1.4301 | SUS 304 | S30400 | 304S31 | Z7CN18‐09 | 08Х18Н10 | X5CrNi18-10 |
| SS 304L | 1.4306 / 1.4307 | SUS 304L | S30403 | 3304S11 | Z3CN18‐10 | 03Х18Н11 | X2CrNi18-9 / X2CrNi19-11 |
| SS 304H | 1.4301 | – | S30409 | – | – | – | – |
| SS 310 | 1.4841 | SUS 310 | S31000 | 310S24 | – | 20Ch25N20S2 | X15CrNi25-20 |
| SS 310S | 1.4845 | SUS 310S | S31008 | 310S16 | – | 20Ch23N18 | X8CrNi25-21 |
| SS 310H | – | – | S31009 | – | – | – | – |
| SS 316 | 1.4401 / 1.4436 | SUS 316 | S31600 | 316S31 / 316S33 | Z7CND17‐11‐02 | – | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SS 316L | 1.4404 / 1.4435 | SUS 316L | S31603 | 316S11 / 316S13 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | 03Ch17N14M3 / 03Ch17N14M2 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
| SS 316H | 1.4401 | – | S31609 | – | – | – | – |
| SS 316Ti | 1.4571 | SUS 316Ti | S31635 | 320S31 | Z6CNDT17‐123 | 08Ch17N13M2T | X6CrNiMoTi17-12-2 |
| SS 317 | 1.4449 | SUS 317 | S31700 | – | – | – | – |
| SS 317L | 1.4438 | SUS 317L | S31703 | – | – | – | X2CrNiMo18-15-4 |
| SS 321 | 1.4541 | SUS 321 | S32100 | – | – | – | X6CrNiTi18-10 |
| SS 321H | 1.4878 | SUS 321H | S32109 | – | – | – | X12CrNiTi18-9 |
| SS 347 | 1.4550 | SUS 347 | S34700 | – | – | 08Ch18N12B | X6CrNiNb18-10 |
| SS 347H | 1.4961 | SUS 347H | S34709 | – | – | – | X6CrNiNb18-12 |
| SS 904L | 1.4539 | SUS 904L | N08904 | 904S13 | Z2 NCDU 25-20 | STS 317J5L | X1NiCrMoCu25-20-5 |
Jassem Tube Fittings is a leading supplier and stockist of premium Stainless Steel Manifold Valves in Doha, Qatar. Our products are extensively used across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our advanced finishing techniques distinguish us in the metal industry. We remain dedicated to consistently providing top-quality manifold valves while effectively meeting the needs of our customers, ensuring reliability and superior performance in every application.
Contact us to get a quick quote for your requirement.
Stainless Steel Manifold Valves find extensive use in industries such as oil and gas, petrochemical, chemical processing, power generation, and instrumentation. They are essential for isolating, equalizing, venting, and calibrating pressure instruments like transmitters and gauges. By integrating multiple valves into a compact assembly, they not only save installation time but also minimize the risk of leaks, enhancing overall efficiency. These valves are crucial for maintaining optimal performance and safety in various applications, making them a vital component in many industrial processes.
Please feel free to contact us if you need any further information or for enquiry.
